เรือขุดชนิดหัวขุด ( Multi-Purpose Dredger)


รุ่น NAGA MARK I

เรือขุดชนิดหัวขุด กำลัง 350 แรงม้า พร้อมหัวขุดไฮดรอลิค



  Multi-purpose Dredger

equiped with 350 hp engine and a cutter suction head.





1.General Specification: NAGA MARKII with BELL200

- Length overall exclude Boom & Arm (Transportation) ---------------- 12,400 mm.
- Width overal                              ----------------  6,400 mm.
- Height (Include cabin)                 ----------------  3,650 mm.
- Total weight without Amphibious pontoon ----  21,500 Kg.
- Total weight with Amphibious pontoon --------  34,245 Kg.

- Main Pontoon LxWxH
     Length ----------  10,500 mm.
     Width -----------  3,400 mm.
     Height ----------  1,200 mm.
- Side Pontoon 2x each LxWxH
     Length ----------  5,000 mm.
     Width -----------  1,500 mm.
     Height ----------  1,200 mm.

- Spud Length -----  9,500 mm.
- Max. Dredging Depth -------  6.60 meters
- Dredging Angle @Dredging Position -------  160 Degrees
- Dredging Width -------------  12.40 meters

- Steel Specification: Steel Grade EN 10027-1 S355
     Main Pontoon
          Bottom plates -----  6.00 mm.
          Side plates -----  6.00 mm.
          Deck plates ----- 6.00 mm.
     Side Pontoon
          Bottom plates -----  4.00 mm.
          Side plates -----  4.00 mm.
          Deck plates -----  4.00 mm.

2. Cabin and Instrument Specification:
     - One-man operation
     - Air Conditioner included
     - Sound Suppression and Heat Proof Cabin
     - LED Chassis light, Left and Right-hand boom lights, Cabin light
     - Controller Seat with air-adjustable suspension

3. Dredger Pump Specification: BELL200
     - Capacity Max. --------  800 m3/hr.
     - Suction diameter -----  200 mm.
     - Pressure diameter ----  200 mm.
     - Spherical passage ----  125 mm.
     - Hydraulic Pressure ---  250 bar
     - Cutter head Diameter ----  650 mm.
     - Pump Type ------  Centrifugal, Single Stage Casing Pump
     - Cutter head power ------  20 KW

4. Engine Specification:
     - Main Engine Power ---------------  260 (354) KW(HP)
          Brand --------------  FPT
          Model -------------  C87 ENT
          RPM ---------------  2,100
          Displacement -----  8,700 cc.
     - Fuel Tank Capacity ----------  800 Liter
     - Emergency engine shutoff switch
     - Auto engine speed control
     - Fault Alarm monitor
     - Telematic = Fuel indcator, Hour meter, RPM meter, Position and Route indicator

5. Performace Specification:
     - Digging Bucket Capacity -----------  0.9 m3
     - Weed Bucket Capacity --------------  1.3 m3, 2.50 m. Length
     - Dredging Pump Capacity -----------  800 m3/hr.

6. Hydraulics Performace and Specification:
     The cutter motor and dredging pump operates by hydraulic. Drive by 2 main pumps, controlled in the cabin.
     - Main System Max. flow ------------  558 l/min
     - Max. Pressure equipment -----------  5,076 psi
     - Hydraulic Tank Capacity -----------  500 Liters
     - DEF Tank -------------  80 Liters
     - Cooling System -----------  40 Liters

7. Electrical system:
     The electrical system is 24V system, power by Maintenance-free 1,000 CCA batteries Centralized electrical disconnect switch

8. Lighting and Signals
     - Dredging indicator light
     - Signaling light
     - Warning horn
     - LED chassis light
     - Left- and right-hand boom lights
     - 2x Cabin lights
     - 10x Exterior lights
     - Depth indicator

9. Thruster Specification:
     - Total weight --------------  90 kg.
     - Propeller diameter -------  405 mm.
     - MAX. power -------------  40 kw.
     - Adjustable up and down

10. OPTIONAL:
     - Amphibious Carriage Pontoons. Model NAGA MARK II function is supporting Amphibious Carriage pontoons as an option
